ADVANCED RUGGED MISSION-CRITICAL COMMUNICATION

MIL-STD 810 CERTIFIED PROFESSIONAL PORTABLE RADIO

RL-328K

Rexon Technology RM-03N professional analog mobile radio is the best choice to be installed in the vehicles and any transportation. RM-03N professional analog mobile radio has the maximum 50W output power. When the full power is not required, the “lower power” can be set to 25W, 10W, and even 5W to save the power consumption. The receiving / transmitting frequency range is from 66 to 480MHz with three frequency bands to be selected. RM-03N professional analog mobile radio overall design adopts a simple operation interface and an amber luminous large subtitle screen display ensures excellent visibility.

File download

Share

  • Professional Frequency Range: Operates in VHF (136-174MHz) and UHF (400-470MHz / 450-520MHz).

  • Rugged Durability: Complies with MIL-STD 810 C/D/E/F and features an IP54 rating for dust and water resistance.

  • Large Memory: Provides 256 programmable channels with 16-channel groups.

  • Advanced Signaling: Supports 5-Tone, 2-Tone, DTMF, and CTCSS/DCS encoding and decoding.

  • User Interface: Equipped with an 8-character alphanumeric display and a backlit keypad.

  • Emergency Functions: Includes a Lone Worker function, Man Down (optional), and an Emergency Siren.

  • Audio Quality: Features a built-in voice compander for clearer audio and a 500mW audio output.

Features
Specifications
Frequency Range
VHF: 136-174MHz / UHF: 400-470MHz, 450-520MHz
Channel Capacity
256 Channels / 16 Groups
Channel Spacing
12.5KHz / 20KHz / 25KHz
Operating Voltage
7.4V DC
Battery Life
More than 10 hours (with 1500mAh Li-ion battery)
Frequency Stability
±2.5ppm
Operating Temperature
−30∘C to +60∘C
Dimensions
105(H)×61(W)×35(D)mm
Weight
Approx. 260g (including battery and antenna)

Transmitter

  • Output Power: 5W / 1W (VHF) and 4W / 1W (UHF).

  • Modulation Type: 16K $\phi$ F3E / 11K $\phi$ F3E.

  • Spurious & Harmonics: 70dB.

  • FM Noise: 45dB (Wide) / 40dB (Narrow).

  • Audio Distortion: Less than 3%.

Receiver

  • Sensitivity: 0.25 $\mu$V (12dB SINAD).

  • Adjacent Channel Selectivity: 70dB (Wide) / 60dB (Narrow).

  • Intermodulation: 65dB.

  • Spurious Response Rejection: 70dB.

  • Audio Power Output: 500mW (with less than 10% distortion).
